DNB Grapple Range

Download the DM Breaker Equipment Catalogue

DOWLOAD

Small Grapples

TF010

Specification Unit TF010
Weight kg 50
Total Length A mm 750
Jaw Opening B mm 865
Upper Arm Width C¹ mm 124
Lower Arm Width C² mm 238
Pressure (cylinder) bar 210
Oil Flow (cylinder) lpm 15~35
Rotating Fixed
Excavator ton 0.7~2.0

TF015

Specification Unit TF015
Weight kg 115
Total Length A mm 950
Jaw Opening B mm 1080
Upper Arm Width C¹ mm 170
Lower Arm Width C² mm 300
Pressure (cylinder) bar 210
Oil Flow (cylinder) lpm 20~45
Rotating Fixed
Excavator ton 1.5~3.0

TF030

Specification Unit TF030
Weight kg 180
Total Length A mm 1100
Jaw Opening B mm 1250
Upper Arm Width C¹ mm 202
Lower Arm Width C² mm 370
Pressure (cylinder) bar 210
Oil Flow (cylinder) lpm 30~75
Rotating Fixed
Excavator ton 2.5~5.0

TF050

Specification Unit TF050
Weight kg 300
Total Length A mm 1195
Jaw Opening B mm 1360
Upper Arm Width C¹ mm 230
Lower Arm Width C² mm 390
Pressure (cylinder) bar 210
Oil Flow (cylinder) lpm 40~80
Rotating Fixed
Excavator ton 4.5~8.0

Medium Grapple

TF060

Specification Unit TF060
Weight kg 730
Total Length A mm 1773
Jaw Opening B mm 1890
Upper Arm Width C¹ mm 324
Lower Arm Width C² mm 560
Pressure (cylinder) bar 150-240
Oil Flow (cylinder) lpm 40~80
Rotating Fixed
Excavator ton 12~18

Product Details

The DNB brand includes a wide range of total solutions for mini excavators, built and designed with the vast Australian country in mind. Inclusive in this range supplied by DM Breaker Equipment is the Mini Grapple, specifically designed for the smaller machines. Attachable to excavators, wheel loaders and backhoes, the Mini Grapple makes the perfect accessory for any collection of plant. The best raw materials, including HARDOX, are used to manufacture the Mini Grapple for reliability.


The DNB Mini Grapples are the perfect accessory for smaller machines. Excellent for logs, stones, pipework or scrap metal. Built with high strength and wear-resistant materials (HARDOX,) the DNB Mini Grapple is lightweight and highly durable. They feature a fixed mount and slim design with long fingers in order to access those tight areas and a 4-bar linkage system for fast motion and wide opening.
